Outdoor LED Sign Panels
Description
Characteristics
The outdoor led sign panels is a high-end display technology with a brightness exceeding 5500CD, clear picture quality, smooth picture and delicate colors. This kind of display uses a new type of high-brightness SMD lamp beads, with a viewing angle of 160 degrees. The LED outdoor display is not only energy-saving and environmentally friendly, but can also work 24 hours a day, and can fully adapt to various harsh outdoor conditions. Environment, it has various features such as anti-corrosion, waterproof, moisture-proof, lightning-proof, and shock-proof. The life of the outdoor led sign panels can be as long as more than 100,000 hours.
Outdoor Led Sign Panels Has High Brightness:
Because it is outdoors for a long time, the brightness cannot be as bright as an indoor screen. Nowadays, the standard outdoor led sign panels generally has a brightness of more than 5500cd, but the brightness can reach more than 10000cd according to customer requirements. In this way, we can clearly see it even under strong light, which is a visual effect for users. is very good.
Advantages
The outdoor led sign panels only energy-saving and environmentally friendly, but can also work 24 hours a day, and can fully adapt to various harsh outdoor environments. They are anti-corrosion, waterproof, moisture-proof, lightning-proof, shock-proof and other features.
Good viewing effect
Product packaging method
Escort the products to ensure transportation safety
Packaging
| Wooden box |
| Unit board packaging |
| Air flight case |
| Simple wooden frame |
Parameter Specific
|
Parameter category |
parameter |
Parameter value |
|
Module parameters |
Parameters / Model |
OPO-LD3S03 |
|
Pixel structure |
SMD2121LED |
|
|
Pixel distance(mm) |
3.076 |
|
|
Module resolution(W×H) |
104×52=5408 |
|
|
Module size(mm) |
320×160×16.6 |
|
|
Module weight(kg) |
0.46 |
|
|
Module input voltage(V) |
5±0.1 |
|
|
Modue maximum current(A) |
≤5 |
|
|
Module maximum power consumption(W) |
≤25 |
|
|
Box parameters |
Box module composition(W×H) |
2×3 |
|
Box resolution(W×H) |
208×156 |
|
|
Box size(mm) |
640×480×70 |
|
|
Box area(m2) |
0.3072 |
|
|
Box weight(kg) |
6～8 |
|
|
Box pixel density(点/m2) |
105625 |
|
|
Level up degree of box(mm) |
≤0.2 |
|
|
Maintenance mode |
Post-ma(Can be customized before maintenance) |
|
|
Box material |
Die Cast Aluminum |
|
|
Electrical parameters |
Box maximum power consumption(W) |
160 |
|
Average power consumption of box(W) |
54 |
|
|
Power supply requirements |
AC90V－132V/ AC186V－264V,Frequency47Hz～63Hz |
|
|
Optical parameters |
Monochromatic brightness correction |
Yes |
|
Single point chroma correction |
Yes |
|
|
White balance brightness(nits) |
≥500 |
|
|
Color Temperature(K) |
2000～9500 |
|
|
Perspective |
140/120 |
|
|
Brightness/Chromatic Uniformity |
≥99% |
|
|
Contrast |
5000:01:00 |
FAQ
Q: How much do outdoor LED signs cost?
Q: What is the difference between indoor and outdoor LED panels?
